PANASONIC PE77U
Write down all values data before make any change.
Once a value is changed, THE CHANGE IS MADE.
Press Volume down button, Hold down the button ON THE PLASMA TV.
Press three times the RECALL button on remote control.
The Service Menu mode will comes up.
To navigate main menu Use {1} {2} on remote control.
To navigate sub-menu Use {3} {4} on remote control items.
To change item value Use {VOL+} {VOL -} on remote control.
To save Turn off Power to exit service mode.
Service Menu Panasonic MX-3MX-3C
CTV Service Mode
Simultaneously press 'RECALL' on remote control and
'VOL-' local. Exit: 'NORMAL' on remote control.
Service Menu Panasonic 1996
Panasonic TV's after 1996 can be set to "Serviceman Mode" with the following remote control sequence:
First, select the SET-UP icon and select CABLE mode.
Then, select the TIMER icon and set the SLEEP timer for 30 second.
Next, press the ACTION button twice to get out of the menus.
Now, change to channel 124.
Then, adjust the volume to minimum (0).
You're almost there - Hit the VOL down button on the TV itself (not on
the remote) and a red "CHK" should appear in the upper corner.
Now, if you press the ACTION and volume down buttons (again, on the TV,
not the remote) you will toggle between AGING and factory setting modes.
Select factory setting modes (Serviceman mode). The POWER button on the
remote control will select one of the five Serviceman Adjustment modes.
The modes are B - Serviceman VCJ SUB Adjustments. These include
sub-tint, sub-color, sub-brightness, sub-contrast,
colorkiller/ABL/gamma, audio and video adjustment, and vertical size.
C - Serviceman VCJ Cut-off adjustments. These include Red, Green
and Blue cut-off, red and blue drive, automatic fine tuning
(AFT), RF AGC (RF gain control), horizontal center, beam limit,
etc.
S - Serviceman Options Adjustments. These involce the PIP and
clock.
M - Serviceman MTS (Stereo/SAP) adjustments.
CHK - the mode you first entered. Normal picture and sound, lets
you check things over and still have a hotkey into the
service menu.
There is one more adjustment that isn't in the five modes, it's
global. When in either the yellow or red CHK mode, you can press
RECALL on the remote control to enter the purity firld check mode.
This lets you select a pure white, red, green, or blue screen. A
good thing to walk away from if you just want to temporarily freak
out the floor manager, but it will be fixed as soon as the TV is
turned off. To get out of Serviceman mode, press ACTION and POWER on the
remote control cimultaneously for at least 2 seconds. The TV will
momentarily shut off and then comes back on.
Service Menu Panasonic CT-G2159E
Turn on TV and using the remote control.
Step 1) Select the SET-UP in the main menu and then select the mode CABLE the option ANTENA.
Step 2) Select TIMER icon and set the timer sleep active 30 second.
Step 3) Press ACTION twice to exit the menu and tune to the channel at 124.
Step 4) Adjust the volume to minimum, Press enter again then volume down.
service mode is CHK. To exit press ACTION and POWER simultaneously for two seconds.
Panasonic CT-215785
Factory codes for panasonic tv
Turn on TV, short-circuit points FA1 - FA2. Press ACTION (or MENU) and
VOL + simultaneously. Press POWER on the remote control to select
Service Menu Panasonic TX-28W3E
Adjust the bass to maximum, treble to minimum, press RESET on the remote
control and while in the TV-VOL. Using the Teletext press RED and GREEN
selects the item with Blue
and Yellow line values. To store
the new press STORE. To exit NORM (normalization).
Service Menu Panasonic CT-Z1422
Simultaneously press the Volume down button on the TV and press 9 at the
remote control for more than 1 second. With channel up or down select
options with volume up
or down adjusts the value. To exit, press ACTION in the remote control
Service Menu Panasonic MX-3
CTV Hotel Mode
ON: Press simultaneously 'OFF TIMER' on remote control and 'CH.UP' local.
OFF: Press simultaneously 'OFF TIMER' on remote control and 'VOL-' local.
Service Menu Panasonic TAU
With the TV on, adjust the volume to a minimum, put the key in OFF-ON TIMER.
Press RECALL on the remote control and simultaneously in the TV-VOL. With keys 1 and
2, selects nodes adjustment (CHK1, CHK2, ...) with the keys 3 and 4 selected items with VOL + / - adjusts the values.
Panasonic Plasma 3UY
Press the volume down & hold down the button on the plasma TV display.
Press 3 times the STATUS button on the remote control.
Status button is the one below Power button
The Service Menu mode CAT will comes up.
CAT is Computer Aided Test Menu
To select a mode parameter use the cursors keys on the remote control.
And press the Action key {} to access the menu.
To exit mode Press the R button.
Service Menu Panasonic TX-25W3E
Increase the bass to maximum, decrease treble to minimum, press RESET on
the remote control and while in the TV-volume. Using the Teletext press
RED and GREEN selects the
item with Blue and Yellow line values. To store the new press STORE. To exit NORM (normalization).
Service Menu Panasonic EURO-2
CTV Service Mode
In Sound-Menu Low-tone-regel to maximum and
High-tone-regel to minimum. Press 'F' button on TV.
Then press VOL- on TV and REVEAL on remote control in
some time. Select press red and green buttons.
Adjust press yellow and blue buttons. Store press
'STR'. Exit press 'N' on remote control.
Panasonic TX-33AK10.
Bass to max.
Treble to min.
Hold down "index"
Press "-" (minus) on the front of the set
Service Menu Panasonic TX-29AK1
Increase Bass to maximum. Decrease Treble to minimum. Hold down "index" Press "-" (minus) on the TV panel.
This Procedure works on the PK1 series as well and will work on TX-33AK10 series.
Service Menu Panasonic MX-3C
CTV Hotel Mode
ON: Press simultaneously 'OFF TIMER' on remote control and 'CH.UP' local.
OFF: Press simultaneously 'OFF TIMER' on remote control and 'VOL-' local.
Service Menu Panasonic EURO-1
CTV Service Mode
In Sound-Menu Low-tone-regel to maximum and
High-tone-regel to minimum. Press VOL- on TV
and reset on remote control in some time. Select press red
and green buttons. Adjust: yellow and blue
buttons. Store press 'STORE'. Exit switch off the television.
Panasonic CT-215785
Turn on TV, short-circuit points FA1 - FA2. Press ACTION (or MENU) and
VOL + simultaneously. Press POWER on the remote control to select
sub menu of services. With CANAL + / - select the item, with VOL + / --
adjusts the value. To exit press POWER and ACTION (or MENU) simultaneously
2 or 3 seconds.
sumber:viva
.
Without
cassette. Hold the STOP button on the Remotye Control. In addition
press the STOP/EJECT button on the VCR until the pre-set modulator
frequency appears in the display, e.g. 'M591' (591MHz or 36 ch. UHF).
Select line 'OPTIMIZE
